Differential winding + soldering
BJT06 / BJT09 + BJT03- 1. Core and wire review
- 2. Differential winding
- 3. Lead forming/cutting
- 4. Soldering
Process Solutions
Equipment combinations organized by winding, soldering, board threading, foot hanging and sleeving processes.
Process Solutions
Process Flow
Understand Solutions by Process Flow
Process solutions are not just single machines. They connect incoming material, winding, downstream handling and inquiry inputs. Start with product type, then confirm soldering, board threading, foot hanging or sleeving needs.
Common-mode winding + downstream automation
BJT12 + BJT15 / BJT13 + BJT05- 1. Common-mode sample review
- 2. Automatic winding
- 3. Foot hanging or board threading
- 4. Soldering/inspection
Network transformer rings and flat wire
BJT01 / BJT02 / BJT17 / BJT18- 1. Product structure review
- 2. Wire parameter review
- 3. Winding test
- 4. Yield acceptance
Large-ring thick wire and sleeving
BJT19 / BJT07- 1. Incoming material review
- 2. Wire-damage requirement
- 3. Winding or sleeving
- 4. Appearance consistency acceptance
Jun 16, 2026
Common mode inductor winding through-board solution
BJT12 and BJT13 can form a combination of common mode coil winding and board threading processes, which is suitable for reducing reliance on manual threading.
Jun 16, 2026
Common mode inductor winding pins soldering solution
BJT12, BJT15, and BJT05 can form the winding, pin-hanging and soldering back-end process chain of common mode/common differential mode inductors.
Jun 16, 2026
Differential mode inductor winding soldering solution
Use BJT06 or BJT09 to complete the differential mode magnetic surround line, and use BJT03 to implement back-end soldering, which is suitable for mass production of differential mode inductors.
Jun 16, 2026
Flat wire winding solution
BJT18, BJT17 can evaluate flat wire winding solutions by thick wire, thin wire and coil size.
Jun 16, 2026
Network transformer small magnetic surround line solution
BJT01、BJT02 面向 5G、10G 网络变压器和 T1/T2 小磁环自动化生产。
Jun 16, 2026
Toroidal coil automatic casing solution
BJT07 is designed for automatic casing at the back of toroidal coils and toroidal inductors, and can be used as the back-end process equipment after winding.
